The capture and immobilization shields have been designed for use in penitentiary and psychiatric centers. Their wraparound design with 2 symmetrical handles for the operator facilitates the task of immobilizing the resistant subject.
Crowd control shields are manufactured with a proprietary mixture of high-performance polycarbonate resins, which is very different from conventional polycarbonates, because our composition resists torsion without exploding, that is, it bends and returns to its state without breaking.
Other shields made of normal polycarbonate, with little baking time or rapid cooling, cannot withstand this force and end up exploding, turning into multiple bladed weapons, which implies a serious danger for the riot police.
Our shields easily reach resistance levels of 150J of kinetic energy upon impact and even more than 20J of kinetic energy from the punch.
• Made from the latest generation of polycarbonates that offer greater resistance to chemical agents and pressure and lack visual distortion when looking through it.
• Ergonomic grip using 2 aerospace aluminum handles.
• Rounded edges without sharp edges.
• Thermally pre-formed into a concave shape that allows the riot police to immobilize the attacker, preventing him from moving his arms and legs.
• 5-year warranty against any manufacturing defect in polycarbonate.
• Allows video recording from behind the shield without causing distortion. Absence of ribs and/or reinforcements in the shield.
• Polycarbonate density: 1.2 gr/cm3 per ISO 1183.
• Humidity (after drying at 23º in conditioned environment according to ISO 62-4): 0.15%.
• Molding temperature: 180-210 ºC.
• Flexural strength ISO 527-2: 60 Mpa.
• Bending deformation ISO 527-2: 6%.
• Tensile strength ISO 527-2: 60 Mpa.
• Elongation at break ISO 527-2: 70 Mpa.
• Charpy impact test with notching ISO 179: No fracture kj/m2.
• Vicat softening properties ISO 306: 148 ºC
• Thermal transmissibility DIN52612: 0.2 W/mK
• Thermal linear expansion DIN53752-A: 0.065 mm/mC.
• Thermal deviation temperature at 0.45 MPa. ISO 75-2: 139ºC.
• Specific heat capacity: 1.17 J/gK
• Light transmission DIN5036-3: 86%
• Optical refraction index ISO 489: 1.586.
• Electrical-volumetric resistance IEC 60093: 10 µm 10 Ohm.cm
• Dielectric strength IEC 60243-1: 35 kV/mm
• IEC60093 surface electrical resistivity: 10 µm ~ 14 ohm
• Dielectric constant (over 10 3 Hz) IEC 60250: 3.1
• Service temperature between –50 C to +50 C
• Treated with anti-scratch and anti-fog
• EPP88 dimensions: 92x53x0.4 cm thick.
• Weight: 2.5 kg.
• We have the model with identical characteristics to the EPP88 but in size 110x60 cm which is equivalent to the protection called “from head to toe”
• We also have special models with thicknesses of up to 0.7 cm, with V50 anti-fragmentation certification up to 260 m/s.
• Optionally they can be supplied with a Nylon cover for shield protection
• The shields do not include any type of lettering. We have signs with the letters: POLICE, LOCAL POLICE and MILITARY POLICE. Others, please consult.
